Description

Head: Inclined at 30°, 360° rotatable, inter-pupillary distance 54-75 mm, diopter adjustable ±5 on left tube.

Eyepiece: Wide field eyepiece WF10X/18mm

Objective: Achromatic objectives 4X 10X 40X 100X (oil)

Nosepiece: Quadruple nosepiece

Condenser: Abbe Condenser N.A. 1.25 with iris diaphragm and filter holder

Focusing system: Coaxial course and fine adjustments, fine division 0.002mm, coarse stroke 36mm. The coarse adjustment is equipped with friction control

Stage: Double layer mechanical stage 110X125mm, moving range 30x75mm

Illumination: 3W/LED Adjustment, rechargeable batteries with an external 100-240 V battery charger/mains adapter
